RG – 59F Axial Cable
• Solid Bare Copper Wire
• Gas Injected Physical Foam Polyethylene Dielectric
• 1st Shield: Bonded Aluminum Tape;
2nd Shield: Aluminum Alloy Braid
• Jacket PVC Black
Diameter
0.80 mm Nom.
Braiding Coverage
60%
Conductor Resistance
Max. 3.55Ω/100m at 20°C
Capacitance (Nom.)
53.00 pF/m
Characteristic Impedance
75 ± 3 ohm
