Polythelene Insulated 0.4mm
• 1-Piece 90 Meter
• G/WIR-06/02 May 94
• A nylon ripcord is provided for slitting the jacket without damaging the insulated cores
• The outer sheath is FR PVC in grey colour
• Cable Type: 0.4 mm x 1Pair
• Box Dimension: 175 x 175 x 62
| Power | Low Power Loss. |
| Signal Clarity | Low Crosstalk. |
| Safety | Fire Retardant Jacket. |
| Low Signal Loss | Low Attenuation. |
| Electrical Parameters | 0.4 mm Dia. |
| 1. Conductor Resistance (max.) ohms/km at 20 C | 143.0 |
| 2. Mutual Capacitance (max.) nf/km | 50 |
| 3. Insulation Resistance in Air (min.) M-ohms/km | 10.000 |
| 4. Capacitance Unbalance Pair to Pair (max.) pF/km | 250 |
